Rigid Metal Conduit (RMC)
Our Rigid Metal Conduit (RMC) is precision manufactured for reliable, long-lasting value and complete protection for your electrical raceway systems. Manufacturing with high-strength steel allows our RMC to be damage resistant while also allowing bending flexibility to meet your installation needs. Our rigid metal conduit is hot-dipped galvanized with a smooth interior and exterior allowing for easy pulling of wires during installation. It is also coated with a chromate to protect against white rust.
Our threads, 3/4” taper NPT threads (ANSI B1.20.1) are galvanized after cutting to ensure that the threads will be protected against corrosion.
• Smooth hot dipped galvanized interior & exterior
• Standardized bundles
• Listed to Underwriters Laboratories Safety Standard UL 6
• Manufactured in accordance with ANSI C80.1
• Color coded end caps
| Part # | Trade Size Designator | Approx. Weight per 100 ft. | Average Outside Diameter* | Average Wall Tickness | Quantity in Master Bundle | Approx. Weight | Volume | End Cap Color |
|---|---|---|---|---|---|---|---|---|
| in | lbs | in | in | ft | lbs | cu ft | ||
|
.5x10RMC |
1/2" | 82 | 0.840 | 0.104 | 2,500 | 2,050 | 20.8 | Black |
|
.75x10RMC |
3/4" | 109 | 1.050 | 0.107 | 2,000 | 2,180 | 24.3 | Red |
|
1.0x10RMC |
1" | 161 | 1.315 | 0.126 | 1,250 | 2,013 | 21.7 | Blue |
|
1.25x10RMC |
1-1/4" | 218 | 1.660 | 0.133 | 900 | 1,962 | 23.3 | Red |
|
1.5x10RMC |
1-1/2" | 263 | 1.900 | 0.138 | 800 | 2,104 | 27.8 | Black |
|
2.0x10RMC |
2" | 350 | 2.375 | 0.146 | 600 | 2,100 | 33.8 | Blue |
|
2.5x10RMC |
2-1/2" | 559 | 2.875 | 0.193 | 370 | 2,068 | 29.2 | Black |
|
3.0x10RMC |
3" | 727 | 3.500 | 0.205 | 300 | 2,181 | 31.3 | Blue |
|
3.5x10RMC |
3-1/2" | 880 | 4.000 | 0.215 | 250 | 2,200 | 34.7 | Black |
|
4.0x10RMC |
4" | 1,030 | 4.500 | 0.225 | 200 | 2,060 | 33.7 | Blue |
*Outside Diameter Tolerances:
+/- .005 in. (.13mm) for Trade Sizes 1/2” (16mm) through 1” (25mm)
+/- .0075 in. (.19mm) for Trade Sizes 1-1/4” (36mm) through 2” (53mm) +/- 0.10 in. (.25mm) for Trade Sizes 2-1/2” (63mm) through 4” (103mm)
**Wall Thickness Tolerances:
+ 0.15 in. (.38mm) and - .000 for Trade Sizes 1/2” (13mm) through 2” (53mm)
+ 0.20 in. (.51mm) and - .000 for Trade Sizes 2-1/2” (63mm) through 4” (103mm) Note: Length = 10 ft. (3.05M) with a tolerance of +/- .25 in. (6.35mm)
